Golf Cart Tire Speed Rating and Load Rating Explained

Golf Cart Tires Collage

Golf Cart Tire Speed Rating and Load Rating Guide

Read Time: 4 minutes
Summary:

  • How to read tire speed and load ratings, and their importance.
  • Detailed charts for load and speed ratings.

How to Read Golf Cart Tire Speed Ratings

Golf cart tires with speed and load ratings will have a number-letter combination (for example: 67M) printed somewhere on the tire's sidewall. The number denotes the load rating, while the letter represents the speed rating.

Golf Cart Tire Speed and Load Rating on Sidewall

In the image above, you can see that the load rating of this 205/50-10 tire is " 67", and the speed rating is "M".

  • Speed Rating is a letter from A to Z that indicates the maximum speed a tire can safely maintain over time while carrying its maximum Load (Load Rating). This "speed rating letter" represents the max speed of the tire in Miles Per Hour.
  • Load Rating is a numerical code that indicates the maximum load that a tire can carry, when traveling at the tire's Max Speed Rating.
  • The two ratings depend on each other, which is why they are listed together.

Load and Speed Rating Tables

The rating values found in the charts below are the most common golf cart tire speed ratings and golf cart tire load ratings:

Golf Cart Tire Load Rating Table

Load IndexPounds
50 419 lbs
51 430 lbs
52 441 lbs
53 454 lbs
54 467 lbs
55 481 lbs
56 494 lbs
57 507 lbs
58 520 lbs
59 536 lbs
60 551 lbs
61 567 lbs
62 584 lbs
63 600 lbs
64 617 lbs
65 639 lbs
66 661 lbs
67 677 lbs
68 694 lbs
69 716 lbs
70 739 lbs
71 761 lbs
72 783 lbs
73 805 lbs
74 827 lbs
75 852 lbs
76 882 lbs
77 908 lbs
78 937 lbs
79 963 lbs
80 992 lbs
81 1019 lbs
82 1047 lbs
83 1074 lbs
84 1102 lbs
85 1135 lbs
86 1168 lbs
87 1201 lbs
88 1235 lbs
89 1279 lbs
90 1323 lbs
91 1356 lbs
92 1389 lbs
93 1433 lbs
94 1477 lbs
95 1521 lbs
96 1565 lbs
97 1609 lbs
98 1653 lbs
99 1709 lbs
100 1764 lbs

The more weight you are planning to put on your golf cart (extra passengers, coolers, etc.) the more important the load rating of your tires becomes. Most golf cart tires will not have Load Index of lower than 57 (or 500lbs) at minimum.

Golf Cart Tire Speed Rating Chart

Speed RatingMaximum Speed
A1 3 mph
A2 6 mph
A3 9 mph
A4 12 mph
A5 16 mph
A6 19 mph
A7 22 mph
A8 25 mph
B 31 mph
C 37 mph
D 40 mph
E 43 mph
F 50 mph
G 56 mph
J 62 mph
K 68 mph
L 75 mph
M 81 mph
N 87 mph
P 93 mph

The closer the speed rating is to the end of the alphabet, the better the tire will perform at high speeds. The higher the speed rating, the better the grip but the less the length of the tread life will be.

How Important are these Ratings for Golf Carts?

Speed and load ratings should not be the primary factor in choosing your golf cart tires, as most carts do not exceed 25mph. If you've ever done 25mph in a golf cart, it feels FAST. And more than 25mph feels downright dangerous! Still, for golf carts, speed and load ratings aren't as important as they are in car and truck tires (which need to be able to handle highway speeds).

But as golf carts continue to get used more and more off the course, and used to carry more people and gear using things such as rear seats and cargo beds, tire load rating becomes more important to understand. While not all golf cart tires have these ratings stamped on them, those that do can offer helpful insights into their capabilities when used on your cart.

While speed and load ratings provide important information about tire performance, other factors like terrain and tread design are also very important.

Leading Key Considerations:

  • Terrain & Tread Pattern: Choose golf cart tires with a tread pattern suited for the surfaces you drive on most.
  • Height: Ensure the overall height of the tire and wheel combo fits your cart.
  • Radial vs. Bias: If you do mostly street driving, select a radial golf cart tire to maximize smoothness and tread life of your tires.

Golf Cart Weight

Understanding how much a golf cart weighs is important when it comes to operating your cart safely alongside your tires' max load rating. Most golf cart tires should in theory be able to hold all the weight you could throw at them when loading up what you can fit on a golf cart. But you'll still want to make sure the load rating on your tires indicates the maximum weight they can support won't be more than what you're carrying on-board. Overloading your cart can lead to premature tire wear and even extremely dangerous tire failure. Always check your tire’s load rating to avoid exceeding the weight limit and ensure safe and optimal performance.

For more detailed information and tire recommendations, explore our full lineup of pre-mounted golf cart wheel and tire combos or give us a call at 1-844-422-7884 today!
